The Massey Ferguson 22-20GC is a tractor with a rated power output of 16 hp, positioning it at the lighter end of its class. This model was manufactured from 2007 to 2009 and is equipped with a 3-cylinder diesel liquid-cooled engine, paired with two-wheel drive and a hydrostatic transmission. Its listed operating weight is 658 kg and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
658 kg
Catalogue coverage
Variants represented
2
Richest spec table
47 rows
Recorded power
16 hp
Recorded weight
658 kg
Transmissions
hydrostatic
Production years
2007-2009
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorMassey Ferguson (a part of AGCO)Reference
ManufacturerMTDReference
Sub-Compact Utility tractorReference
Two-wheel driveReference
Final drivesmechanical rearReference
Power steeringReference
Two-post folding ROPS.Reference
Engine
Perkins 0.7L 3-cyl dieselReference
Fuel tank17.4 LReference
Engine14.9 kWReference
PerkinsReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.7 LReference
Power14.9 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)11.9 kWReference
Rear TypeIReference
Rear lift (at ends)464 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase139 cmReference
Weight658 kgReference
Lawn/turf front18x8.50-8Reference
Lawn/turf rear26x12.00-12Reference
Length261 cmReference
Width115 cmReference
Height202 cmReference
Massey Ferguson 22-20GC attachments
137 cm mid-mount mower deckReference
152 cm mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
137 cm mid-mount mower deckReference
152 cm mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
