Tractor · 2002Unverified
Massey Ferguson 2225
Massey Ferguson 2225 — Compact Utility tractor · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
6504 to 6724 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Differential lockelectro-hydraulicReference
Power steeringReference
Wet disc brakesReference
Trailer brakeshydraulicReference
Cab standard with heat. Air-conditioning optional. Flat platform with Two-post ROPS available.Reference
Engine
Perkins 4.0L 4-cyl dieselReference
Fuel tank67.0 LReference
Fuel tank99.9 LReference
Engine50.7 kWReference
Perkins 1004-40Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power50.7 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
15-speed sync shuttleReference
30-speed two-speed power shiftReference
Typesync shuttleReference
Gears15 forward and reverseReference
Clutch304.8mm cerametallic dry discReference
A 30 KPH 12-speed shuttle is standard with two-wheel drive, a 40 KPH 15-speed shuttle is standard with four-wheel drive. Also available with creeper.Reference
TransmissionSpeedshiftReference
Typetwo-speed power shiftReference
Gears30 forward and reverseReference
The optional Speedshift provides a two-speed power shift to the standard transmission (24 gears with two-wheel drive). Also available with creeper.Reference
PTO & Hydraulics
Pressure180.0 barReference
Pump flow54.1 lpmReference
Steering flow29.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2100 kgReference
Rear lift3400 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
4WD Wheelbase215 cmReference
Weight6504 to 6724 poundsReference
Lawn/turf front360/70R20Reference
Lawn/turf rear420/70R30Reference
Length402 cmReference
Width197 cmReference
Height (cab)243 cmReference
2WD Weight2950 kgReference
4WD Weight3050 kgReference
4WD Ground clearance39 cmReference
Front tread159 to 184 cmReference
Rear tread155 to 196 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
