Tractor · 2003Unverified
Massey Ferguson 2405
Massey Ferguson 2405 — Compact Utility tractor · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
1250 kg
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulicReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post mid-mount folding ROPS.Reference
Engine
Mitsubishi 1.5L 4-cyl dieselReference
Fuel tank37.9 LReference
Fuel tank53.0 LReference
Engine24.6 kWReference
MitsubishiReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
EmissionsStage IIReference
Power24.6 kWReference
Rated RPM3000Reference
Torque84.1 NmReference
Torque RPM1900Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutch230mm dry discReference
Four gears in three ranges with left-hand shuttle.Reference
PTO & Hydraulics
Pump flow29.9 lpmReference
Rear TypeIReference
Rear lift1200 kgReference
Front lift400 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Mid PTO Type1000/2000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase173 cmReference
Weight1250 kgReference
Front tire6.50/80-12Reference
Rear tire280/70-18Reference
Standard tires (ag)Front: 6.50/80-12. Rear: 280/70-18Reference
Length305 cmReference
Height (hood)126 cmReference
Ground clearance34 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
Massey 2410 with 320/70R20 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
