Lawn Tractor · 1998Unverified
Massey Ferguson 2414H
Massey Ferguson 2414H — Riding lawn mower · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
188 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerSimplicityReference
Riding lawn mowerReference
Built in Port Washington, Wisconsin, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
14HP Kohler 1-cyl gasolineReference
Fuel tank7.6 LReference
Kohler CommandReference
gasolineReference
1-cylinderReference
air-cooledReference
Power (gross)10.4 kWReference
Rated RPM3400Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Wheelbase109 cmReference
Weight188 kgReference
Front tire13x5.0-6Reference
Rear tire16x6.5-8Reference
Lawn/turf front13x5.0-6Reference
Lawn/turf rear16x6.5-8Reference
Length154 cmReference
Width83 cmReference
Height (steering wheel)104 cmReference
Weight188 kgReference
Massey Ferguson 2414H attachments
34" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
34" Mower deck
Typemid-mount Massey FergusonReference
Type2-bladeReference
Cutting width86 cmReference
Overall width115 cmReference
Cut height2 to 9 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
