Tractor · 2003Unverified
Massey Ferguson 2415
Massey Ferguson 2415 — Compact Utility tractor · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
1319 kg
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulicReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post mid-mount folding ROPS.Reference
Engine
Mitsubishi 1.8L 4-cyl dieselReference
Fuel tank37.9 LReference
Fuel tank53.0 LReference
Engine35.0 kWReference
MitsubishiReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
EmissionsStage IIReference
Power35.0 kWReference
Rated RPM3000Reference
Torque122.0 NmReference
Torque RPM2000Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutch230mm dry discReference
Four gears in three ranges with left-hand shuttle.Reference
PTO & Hydraulics
Pump flow29.9 lpmReference
Rear TypeIReference
Rear lift1200 kgReference
Front lift400 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Mid PTO Type1000/2000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase173 cmReference
Weight1319 kgReference
Front tire7.50-16Reference
Rear tire12.4R24Reference
Standard tires (ag)Front: 7.50-16. Rear: 12.4R24Reference
Length305 cmReference
Height (hood)132 cmReference
Ground clearance39 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
Massey 2410 with 320/70R20 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
