Tractor · 2005Unverified

Massey Ferguson 2430

Name: Massey Ferguson 2430
Brand: Massey Ferguson

Massey Ferguson 2430 — Utility tractor · 66 hp. Reference specifications; pending source verification.

The Massey Ferguson 2430 is a tractor model with a rated power of 66 hp, a mid-range figure for its class. It was manufactured from 2005 to 2007. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine paired with four-wheel drive and a powershift transmission. It has an operating weight of 3050 kg and is suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

66 hp

Weight

3050 kg

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

66 hp

Recorded weight

3050 kg

Transmissions

15-speed

Production years

2005-2007

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

Four-wheel driveReference

Variants

2430STstandardReference

2430GElow-profileReference

Engine

Perkins 3.3L 4-cyl dieselReference

Fuel tank90.1 LReference

Engine49.0 kWReference

Perkins 800Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke94 x 120 mmReference

EmissionsTier IIReference

Power49.0 kWReference

Fuel systemdirect injectionReference

Rated RPM2500Reference

Torque210.2 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Transmission

15-speedReference

15-speed power shuttleReference

30-speed two-speed power shiftReference

Gears15 forward and reverseReference

Clutchdry discReference

Five gears in three ranges with mechanical shuttle.Reference

Typepower shuttleReference

Clutchwet discReference

TransmissionSpeedshiftReference

Typetwo-speed power shiftReference

Gears30 forward and reverseReference

Speedshift adds a two-speed power shift to the basic shuttle transmission. Optional creeper range expands total gears to 60 in each direction.Reference

PTO & Hydraulics

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift2100 kgReference

Rear lift3400 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase215 cmReference

Weight3050 kgReference

Front tire12.4R20Reference

Rear tire14.9R30Reference

Standard tires (ag)Front: 12.4R20. Rear: 14.9R30Reference

Length402 cmReference

Width187 cmReference

Height (cab)240 cmReference

Ground clearance41 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Speeds

With 16.9R34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
