Tractor · 2005Unverified
Massey Ferguson 2435
Massey Ferguson 2435 — Utility tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
3050 kg
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Utility tractorReference
Four-wheel driveReference
Variants
2435STstandardReference
2435GElow-profileReference
Engine
Perkins 3.3L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine56.0 kWReference
Perkins 800Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke94 x 120 mmReference
EmissionsTier IIReference
Power56.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2500Reference
Torque234.6 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
15-speedReference
15-speed power shuttleReference
30-speed two-speed power shiftReference
Gears15 forward and reverseReference
Clutchdry discReference
Five gears in three ranges with mechanical shuttle.Reference
Typepower shuttleReference
Clutchwet discReference
TransmissionSpeedshiftReference
Typetwo-speed power shiftReference
Gears30 forward and reverseReference
Speedshift adds a two-speed power shift to the basic shuttle transmission. Optional creeper range expands total gears to 60 in each direction.Reference
PTO & Hydraulics
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2100 kgReference
Rear lift3400 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase215 cmReference
Weight3050 kgReference
Front tire12.4R20Reference
Rear tire14.9R30Reference
Standard tires (ag)Front: 12.4R20. Rear: 14.9R30Reference
Length402 cmReference
Width187 cmReference
Height (cab)240 cmReference
Ground clearance41 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
With 16.9R34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
