Lawn Tractor · 2010Unverified
Massey Ferguson 25195H
Massey Ferguson 25195H — Lawn tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
227 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerSimplicityReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Regent 19.5/38similar Simplicity modelReference
Engine
19.5HP Briggs & Stratton 499cc 1-cyl gasolineReference
Fuel tank13.2 LReference
Briggs & Stratton 31Q677Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement30.5 ciReference
Bore/Stroke91 x 78 mmReference
Power (gross)14.5 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K46Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase127 cmReference
Weight227 kgReference
Front tire15x6.0-6Reference
Rear tire20x8.0-8Reference
Lawn/turf front15x6.0-6Reference
Lawn/turf rear20x8.0-8Reference
Length180 cmReference
Width93 cmReference
Height (steering wheel)114 cmReference
Front axleCast-ironReference
Rear axle19 mmReference
Massey Ferguson 25195H attachments
38" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery CCA195Reference
Battery volts12Reference
38" Mower deck
Typemid-mount Massey FergusonReference
Type2-blade with manual liftReference
Cutting width96 cmReference
Overall width127 cmReference
Cut height2 to 10 cmReference
Cut positionsinfiniteReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
