Lawn Tractor · 2006Unverified
Massey Ferguson 2522H
Massey Ferguson 2522H — Lawn tractor · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
195 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerSimplicityReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Regent 22/44similar Simplicity modelReference
Engine
22HP Briggs & Stratton 721cc 2-cyl gasolineReference
Fuel tank13.2 LReference
Briggs & Stratton 44K777Reference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement44 ciReference
Bore/Stroke79 x 73 mmReference
Power (gross)16.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K46 HDReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase127 cmReference
Weight195 kgReference
Front tire15x6-6Reference
Rear tire22x8-8Reference
Weight50 kgReference
Lawn/turf front15x6-6Reference
Lawn/turf rear22x8-8Reference
Length180 cmReference
Width93 cmReference
Height (steering wheel)114 cmReference
Massey Ferguson 2522H attachments
44" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps9Reference
Battery CCA230Reference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
SnowblowerReference
BladeReference
44" Mower deck
Typemid-mount Massey Ferguson 1695133Reference
Type3-blade with manual liftReference
Cutting width111 cmReference
Overall width142 cmReference
Cut height3 to 10 cmReference
Cut positionsinfiniteReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
