Tractor · 2016Unverified
Massey Ferguson 2606H
Massey Ferguson 2606H — Utility tractor · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
5115 to 5710 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Original price was $24,362 in 2017Reference
Two- or four-wheel driveReference
Final drivesoutboard planetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Simpson 2.6L 3-cyl dieselReference
Fuel tank54.9 LReference
Engine (gross)48.5 kWReference
SimpsonReference
turbocharged intercooled dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement2.6 LReference
Bore/Stroke93 x 127 mmReference
EmissionsTier IVReference
Emission controlexhaust gas recirculation with diesel oxidation catalyst (DOC) (EGR)Reference
Power (gross)48.5 kWReference
Fuel systemelectronic high-pressure common railReference
Rated RPM2000Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed sync shuttleReference
Typesync shuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)41.0 kWReference
Typeopen centerReference
Valves2Reference
Pump flow40.1 lpmReference
Total flow59.4 lpmReference
Rear TypeII/IReference
Rear lift (at 24"/610mm)1249 kgReference
2WD Rear PTOliveReference
4WD Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
2WD Wheelbase204 cmReference
4WD Wheelbase207 cmReference
Weight5115 to 5710 poundsReference
Front tire7.5x16Reference
2WD Rear tire14.9x28Reference
2WD Standard tires (ag)Front: 7.5x16. Rear: 14.9x28Reference
4WD Standard tires (ag)Front: 9.5x24. Rear: 14.9x28Reference
2WD Industrial front11L15Reference
4WD Industrial front10.8/80-18Reference
Industrial rear14.9x24Reference
4WD Industrial front12.5/80-18Reference
4WD Industrial rear16.9x24Reference
2WD Length350 cmReference
4WD Length353 cmReference
Width177 cmReference
Height238 cmReference
2WD Weight2320 kgReference
4WD Weight2590 kgReference
Massey Ferguson 2606H attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Massey Ferguson L135E loaderReference
Massey Ferguson 911X loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
