Tractor · 2016Unverified

Massey Ferguson 2606H

Name: Massey Ferguson 2606H
Brand: Massey Ferguson

Massey Ferguson 2606H — Utility tractor · 65 hp. Reference specifications; pending source verification.

The Massey Ferguson 2606H is a tractor with a rated output of 65 hp, positioning it in the middle of its class in terms of power. This model was first introduced in 2016. It features a 3-cylinder turbocharged intercooled diesel liquid-cooled engine that drives a four-wheel drive system through an 8-speed gearbox. The listed weight of the 2606H is between 5115 and 5710 pounds, making it suitable for tasks on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

65 hp

Weight

5115 to 5710 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

65 hp

Recorded weight

2320 kg

Transmissions

8-speed sync shuttle

Production years

2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Utility tractorReference

Original price was $24,362 in 2017Reference

Two- or four-wheel driveReference

Final drivesoutboard planetaryReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Simpson 2.6L 3-cyl dieselReference

Fuel tank54.9 LReference

Engine (gross)48.5 kWReference

SimpsonReference

turbocharged intercooled dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement2.6 LReference

Bore/Stroke93 x 127 mmReference

EmissionsTier IVReference

Emission controlexhaust gas recirculation with diesel oxidation catalyst (DOC) (EGR)Reference

Power (gross)48.5 kWReference

Fuel systemelectronic high-pressure common railReference

Rated RPM2000Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed sync shuttleReference

Typesync shuttleReference

Gears8 forward and reverseReference

PTO & Hydraulics

PTO (claimed)41.0 kWReference

Typeopen centerReference

Valves2Reference

Pump flow40.1 lpmReference

Total flow59.4 lpmReference

Rear TypeII/IReference

Rear lift (at 24"/610mm)1249 kgReference

2WD Rear PTOliveReference

4WD Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

2WD Wheelbase204 cmReference

4WD Wheelbase207 cmReference

Weight5115 to 5710 poundsReference

Front tire7.5x16Reference

2WD Rear tire14.9x28Reference

2WD Standard tires (ag)Front: 7.5x16. Rear: 14.9x28Reference

4WD Standard tires (ag)Front: 9.5x24. Rear: 14.9x28Reference

2WD Industrial front11L15Reference

4WD Industrial front10.8/80-18Reference

Industrial rear14.9x24Reference

4WD Industrial front12.5/80-18Reference

4WD Industrial rear16.9x24Reference

2WD Length350 cmReference

4WD Length353 cmReference

Width177 cmReference

Height238 cmReference

2WD Weight2320 kgReference

4WD Weight2590 kgReference

Massey Ferguson 2606H attachments

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Massey Ferguson L135E loaderReference

Massey Ferguson 911X loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
