Lawn Tractor · 1999Unverified
Massey Ferguson 2618H
Massey Ferguson 2618H — Lawn tractor · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
263 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerSimplicityReference
Lawn tractorReference
Built in Port Washington, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Broadmoor 18Hsimilar Simplicity modelReference
Engine
18HP Vanguard 622cc 2-cyl gasolineReference
Fuel tank15.1 LReference
VanguardReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement38 ciReference
Bore/Stroke77 x 67 mmReference
Power (gross)13.4 kWReference
Rated RPM3400Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase128 cmReference
Weight263 kgReference
Front tire15x6.0-6Reference
Rear tire20x8.0-8Reference
Lawn/turf front15x6.0-6Reference
Lawn/turf rear20x8.0-8Reference
Length178 cmReference
Width88 cmReference
Height (steering wheel)101 cmReference
Massey Ferguson 2618H attachments
50" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
50" mid-mount mower deckReference
SnowblowerReference
BladeReference
The single-stage snow blower was also available in a 36-inch width.Reference
50" Mower deck
Typemid-mount Massey FergusonReference
Type3-bladeReference
Cutting width127 cmReference
Overall width157 cmReference
Cut height2 to 9 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
