Lawn Tractor · 2011Unverified
Massey Ferguson 2622
Massey Ferguson 2622 — Lawn tractor · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
263 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerSimplicityReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Broadmoor 22/44similar Simplicity modelReference
Engine
22HP Briggs & Stratton 724cc 2-cyl gasolineReference
Fuel tank13.6 LReference
Briggs & StrattonReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement44.18 ciReference
Bore/Stroke79 x 73 mmReference
Power (gross)16.4 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Oil change50 hReference
Transmission
hydrostaticReference
TransmissionTuff Torq K57Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase134 cmReference
Weight263 kgReference
Front tire15x6.0-6Reference
Rear tire22x10.0-10Reference
Lawn/turf front15x6.0-6Reference
Lawn/turf rear22x10.0-10Reference
Length177 cmReference
Height (steering wheel)109 cmReference
Flange rear axle19 mmReference
Massey Ferguson 2622 attachments
44" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery CCA230Reference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
SnowblowerReference
BladeReference
44" Mower deck
Typemid-mount Massey FergusonReference
Typemanual liftReference
Cutting width111 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
