Tractor · 2010Unverified
Massey Ferguson 2660LP
Massey Ferguson 2660LP — Orchard/Vineyard tractor · 81 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
81 hp
Weight
5644 to 6217 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Built in BrazilReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Differential lockstandardReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank100.3 LReference
Engine (gross)60.4 kWReference
Perkins 1104D-44TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
EmissionsTier IIIReference
Power (gross)60.4 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
12-speed partially synchronizedReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutchsingle dry discReference
Four gears with high and low ranges. Synchronized gears and forward/reverse.Reference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Synchronized between gears 2-3 and between slow-fast ranges.Reference
PTO & Hydraulics
PTO (claimed)52.2 kWReference
Typeopen centerReference
Valves1 to 3Reference
Pump flow54.9 lpmReference
Total flow85.2 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1538 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase228 cmReference
Weight5644 to 6217 poundsReference
Front tire9.5L-15SLReference
Rear tire18.4-26 (2WD)Reference
Standard tires (ag)Front: 9.5L-15SL. Rear: 18.4-26 (2WD)Reference
Standard tires (ag)Front: 12.5/80-18 . Rear: (4WD)Reference
Optional tires (ag)Front: 12.5/80-18. Rear: 16.9-24 (4WD)Reference
Optional tires (ag)Front: 11.2-24. Rear: 18.4-26 (4WD)Reference
Length350 cmReference
Length343 cmReference
Width199 cmReference
Height (ROPS)248 cmReference
Shipping weight2560 kgReference
Shipping weight2820 kgReference
Clearance (drawbar)27 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
