Search/Tractor/Massey Ferguson/2680 HD

Tractor · 2010Unverified

Massey Ferguson 2680 HD

Name: Massey Ferguson 2680 HD
Brand: Massey Ferguson

Massey Ferguson 2680 HD — Utility tractor · 97 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

97 hp

Max power

65.7 kW

Weight

6812 to 8505 pounds

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

Built in BrazilReference

Original price$38,288 (2012 8-speed ROPS 2WD )Reference

Original price$43,587 (2012 8-speed ROPS 4WD )Reference

Original price$44,810 (2012 8-speed Cab 4WD )Reference

Original price$52,632 (2012 8-speed Cab 4WD )Reference

Original price$37,582 (2012 12-speed ROPS 2WD )Reference

Original price$42,917 (2012 12-speed ROPS 4WD )Reference

Original price$47,156 (2012 12-speed Cab 2WD )Reference

Original price$51,963 (2012 12-speed Cab 4WD )Reference

Two- or four-wheel driveReference

Final drivesoutboard planetaryReference

Differential lockmechanical rear lock standardReference

Power steeringReference

Hydraulic wet disc brakesReference

Flat platform with two-post folding ROPS. Cab optional with air-condioning.Reference

Variants

2680HDutilityReference

2680LPlow-profileReference

2680HChigh-cropReference

Engine

Perkins 4.4L 4-cyl dieselReference

Fuel tank100.3 LReference

Engine (gross)72.3 kWReference

Perkins 1104D-44TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

EmissionsTier IIIReference

Power (gross)72.3 kWReference

Pre-heatingglow plugsReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Max power65.7 kWReference

Power at rated engine speed64.2 kWReference

Transmission

8-speed synchronized shuttleReference

12-speed partially synchronizedReference

Typesynchronized shuttleReference

Gears8 forward and reverseReference

Clutchsingle dry discReference

Four gears with high and low ranges. Synchronized gears and forward/reverse.Reference

Typepartially synchronizedReference

Gears12 forward and 4 reverseReference

Synchronized between gears 2-3 and between slow-fast ranges.Reference

PTO & Hydraulics

PTO (claimed)61.9 kWReference

PTO (tested)65.7 kWReference

Typeopen centerReference

Valves1 to 3Reference

Pump flow26.5 lpmReference

Pump flow37.9 lpmReference

SCV flow64.3 lpmReference

Total flow94.6 lpmReference

Steering flow30.3 lpmReference

Rear TypeIIReference

Rear lift (at 24"/610mm)1670 kgReference

Drawbarswinging drawbar with hammer strapReference

Rear PTOindependentReference

Clutchwet discReference

Rear PTO Type540Reference

Rear PTO Type540/1000 (optional)Reference

Power at rated PTO speed65.5 kWReference

Dimensions

Wheelbase228 cmReference

Weight6812 to 8505 poundsReference

Front tire10.00-16Reference

Rear tire18.4-30 (2WD)Reference

Standard tires (ag)Front: 10.00-16. Rear: 18.4-30 (2WD)Reference

Standard tires (ag)Front: 13.6-24. Rear: 18.4-30 (4WD)Reference

Standard tires (ag)Front: 320/85R34. Rear: 320/90R50 (High-Crop)Reference

Optional tires (ag)Front: 10.00-16. Rear: 18.4-34 (2WD)Reference

Optional tires (ag)Front: 10.00-16. Rear: 13.6-38 (2WD)Reference

Optional tires (ag)Front: 10.00-16SL. Rear: 15.5-38 (2WD)Reference

Optional tires (ag)Front: 14.9-24. Rear: 18.4-34 (4WD)Reference

Optional tires (ag)Front: 13.6-24. Rear: 13.6-38 (4WD)Reference

Optional tires (ag)Front: 11.2-28. Rear: 15.5-38 (4WD)Reference

Length393 cmReference

Width212 cmReference

Ground clearance55 cmReference

Clearance (drawbar)41 cmReference

Shipping3089 kgReference

Shipping3299 kgReference

Shipping3430 kgReference

Shipping3640 kgReference

4WD Cab Operating3857 kgReference
