Tractor · 2010Unverified
Massey Ferguson 2680LP
Massey Ferguson 2680LP — Orchard/Vineyard tractor · 97 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
97 hp
Weight
6063 to 6945 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Built in BrazilReference
Original price$39,338 (2012 8-speed ROPS 2WD )Reference
Original price$43,398 (2012 8-speed ROPS 4WD )Reference
Original price$38,619 (2012 12-speed ROPS 2WD )Reference
Original price$42,716 (2012 12-speed ROPS 4WD )Reference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Differential lockstandardReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank100.3 LReference
Engine (gross)72.3 kWReference
Perkins 1104D-44TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
EmissionsTier IIIReference
Power (gross)72.3 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
12-speed partially synchronizedReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutchsingle dry discReference
Four gears with high and low ranges. Synchronized gears and forward/reverse.Reference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Synchronized between gears 2-3 and between slow-fast ranges.Reference
PTO & Hydraulics
PTO (claimed)61.9 kWReference
Typeopen centerReference
Valves1 to 3Reference
Pump flow26.5 lpmReference
Pump flow37.9 lpmReference
SCV flow64.3 lpmReference
Total flow94.6 lpmReference
Steering flow30.3 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1670 kgReference
Drawbarswinging drawbar with hammer strapReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540Reference
Dimensions
Wheelbase228 cmReference
Weight6063 to 6945 poundsReference
Front tire9.5L-15SLReference
Rear tire18.4-26 (2WD)Reference
Standard tires (ag)Front: 9.5L-15SL. Rear: 18.4-26 (2WD)Reference
Standard tires (ag)Front: 12.5/80-18. Rear: 16.9-24 (4WD)Reference
Optional tires (ag)Front: 9.5L-15SL. Rear: 16.9-24 (2WD)Reference
Optional tires (ag)Front: 11.2-24. Rear: 18.4-26 (4WD)Reference
Width199 cmReference
Height (ROPS)257 cmReference
Shipping weight2750 kgReference
Shipping weight3150 kgReference
Clearance (drawbar)33 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery CCA750Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
