Lawn Tractor · 2010Unverified
Massey Ferguson 2724H
Massey Ferguson 2724H — Garden tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
308 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerSimplicityReference
Garden tractorReference
Two-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Open operator station with 18-inch adjustable seat.Reference
Variants
Conquest 24/52similar Simplicity modelReference
Engine
24HP Briggs & Stratton 724cc 2-cyl gasolineReference
Fuel tank13.6 LReference
Briggs & Stratton 44M777Reference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement44.2 ciReference
Bore/Stroke79 x 73 mmReference
Power (gross)17.9 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Sparkplug gap0.762 mmReference
Transmission
hydrostaticReference
TransmissionTuff Torq K66Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase134 cmReference
Weight308 kgReference
Front tire16x6.5-8Reference
Rear tire23x10.5-12Reference
Lawn/turf front16x6.5-8Reference
Lawn/turf rear23x10.5-12Reference
Length191 cmReference
Width157 cmReference
Height119 cmReference
Front axleCast-ironReference
Rear axle25 mmReference
Massey Ferguson 2724H attachments
52" mid-mount mower deckReference
bladeReference
2724H Serial Numbers
Location:Serial number decal on the right side of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging amps16Reference
Battery CCA230Reference
Battery volts12Reference
Attachment overview
52" mid-mount mower deckReference
BladeReference
52" Mower deck
Typemid-mount Massey FergusonReference
Type3-blade with manual liftReference
Cutting width132 cmReference
Overall width166 cmReference
Cut height2 to 10 cmReference
Cut positionsinfiniteReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
