Tractor · 1982Unverified
Massey Ferguson 274
Massey Ferguson 274 — 204 Series · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Max power
34.4 kW
Weight
2714 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerLandiniReference
Utility tractorReference
Built in ItalyReference
Original price was $23,000 in 1987Reference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Differential mechanical dry disc brakesReference
Two-post ROPS.Reference
Variants
6830similar Landini modelReference
273similar Massey Ferguson modelReference
Engine
Perkins 3.9L 4-cyl dieselReference
Fuel tank60.6 LReference
Drawbar (tested)34.4 kWReference
Perkins A4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Compression16:1Reference
Rated RPM2200Reference
Starter volts12Reference
Power at rated engine speed41.3 kWReference
Max power34.4 kWReference
Transmission
12-speed synchromeshReference
TypesynchromeshReference
Gears12 forward and 4 reverseReference
Clutch11-inch dual dry discReference
Four gears in three ranges, plus reverse range.Reference
PTO & Hydraulics
PTO (claimed)41.0 kWReference
PTO (tested)41.3 kWReference
Typeopen centerReference
Valves2Reference
Pump flow35.6 lpmReference
Rear TypeIIReference
Controldraft and position controlReference
Rear lift (at 24"/610mm)1664 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1944Reference
Front PTOdirect-driveReference
Front PTO Type2250Reference
Power at rated PTO speed40.5 kWReference
Dimensions
Wheelbase222 cmReference
Weight2714 kgReference
Front tire11.2-24Reference
Rear tire16.9-30Reference
Standard tires (ag)Front: 11.2-24. Rear: 16.9-30Reference
Operating weight2714 kgReference
Ballasted weight3714 kgReference
Clearance (front axle)35 cmReference
Front tread151 cmReference
Rear tread149 to 200 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 12-speed 4WDMay 12 - 26, 1983Link: Nebraska Tractor Test 1521 fileReference
PTO performanceReference
Fuel use12.9 l/hourReference
Fuel use11.7 l/hourReference
Drawbar performanceReference
Gear 8 used for power test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
