Tractor · 1976Unverified
Massey Ferguson 2800
Massey Ferguson 2800 — Row-Crop tractor · 190 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
190 hp
Weight
5896 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Row-Crop tractorReference
Original price was $36,000 in 1977Reference
Two-wheel driveReference
Differential lockhydraulic rearReference
Steeringhydrostatic powerReference
Hydraulic disc brakesReference
Cab standard.Reference
Engine
Perkins 10.5L 8-cyl dieselReference
Fuel tank291.4 LReference
Perkins ATV8.640Reference
turbocharged dieselReference
8-cylinderReference
liquid-cooledReference
Displacement10.5 LReference
Bore/Stroke118 x 121 mmReference
Fuel systemCAV rotary pumpReference
Air cleanerdual stage dryReference
Compression16:1Reference
Rated RPM2500Reference
Starter12Reference
Starter volts12Reference
Oil capacity22.7 LReference
Coolant capacity52.1 LReference
Transmission
24-speed 3-speed power shiftReference
8-speed mechanical shuttleReference
TransmissionMulti-PowerReference
Type3-speed power shiftReference
Gears24 forward and 6 reverseReference
Oil capacity143.9 LReference
Eight forward gears with three power shift speeds in each gear.Reference
Typemechanical shuttleReference
Gears8 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)141.7 kWReference
Typeopen centerReference
Valves2 or 3Reference
Pump flow62.5 lpmReference
Steering flow20.8 lpmReference
Rear TypeIII/II (optional)Reference
Controlposition and draft controlReference
Drawbarswinging drawbarReference
Drawbarheavy-duty wide-swinging (Western)Reference
Rear PTOindependentReference
ClutchhydraulicReference
Rear PTO Type1000 (1.75)Reference
Rear PTO Type1000 (1.375 opt.)Reference
Engine RPM1000@2100Reference
Dimensions
Wheelbase279 cmReference
Weight5896 kgReference
Front tire14L-16.1Reference
Rear tire20.8-38Reference
Ag front14L-16.1Reference
Ag rear20.8-38Reference
Ag front11.00-16Reference
Ag front18.4-16.1Reference
Ag rear23.1-34Reference
Ag rear24.5-32Reference
Ag rear30.5-32Reference
Ag rear18.4-38 (dual)Reference
Ag rear20.8-38 (dual)Reference
Ag rear23.1-34 (dual)Reference
Length482 cmReference
Clearance (front axle)64 cmReference
Clearance (rear axle)39 cmReference
Rear axle95 by 2326 mmReference
Rear axle95 by 3192 mmReference
Rear axle95 by 3985 mmReference
Front tread142 to 203 cmReference
Front tread142 cmReference
Rear tread180 to 233 cmReference
Rear tread180 to 320 cmReference
Rear tread180 to 408 cmReference
Steering wheel221 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps58Reference
Charging volts12Reference
Battery volts12Reference
Massey Ferguson 2800 Height
Hood185 cmReference
Cab284 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
