Lawn Tractor · 1998Unverified

Massey Ferguson 2920LC

Name: Massey Ferguson 2920LC
Brand: Massey Ferguson

Massey Ferguson 2920LC — Garden tractor · 20 hp. Reference specifications; pending source verification.

The Massey Ferguson 2920LC is a lawn tractor model with a rated output of 20 hp, categorising it among higher-powered machines in its class. It was manufactured from 1998 to 2003 and features a 2-cylinder petrol liquid-cooled engine, which drives through two-wheel drive via a hydrostatic transmission. The listed weight is 372 kg, and it is designed for use on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

372 kg

Catalogue coverage

Variants represented

Richest spec table

87 rows

Recorded power

20 hp

Recorded weight

372 kg

Transmissions

hydrostatic

Production years

1998-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorMassey FergusonReference

ManufacturerSimplicityReference

Garden tractorReference

Built in Port Washington, Wisconsin, USAReference

Original price$8,650 (1998 )Reference

Original price$10,300 (2001 )Reference

Two-wheel driveReference

Final drivesspur gearReference

Differential lockmechanical rearReference

Power steeringReference

Disc brakesReference

Open operator station. Hard-side weather cab optional. Two-post ROPS available.Reference

Engine

20HP Kawasaki 617cc 2-cyl gasolineReference

Fuel tank22.7 LReference

Kawasaki FD620Reference

gasolineReference

2-cylinderReference

liquid-cooled horizontal-shaft V-TwinReference

Displacement37.65 ciReference

Bore/Stroke76 x 68 mmReference

Power (gross)14.9 kWReference

Compression9:1Reference

StarterelectricReference

Starter volts12Reference

Oil capacity1.5 LReference

Coolant capacity2.7 LReference

Transmission

hydrostaticReference

TransmissionSundstrand 15UReference

Typeshaft-driven hydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Oil capacity5.7 LReference

Oil typeATF FReference

Oil change400 hReference

Sundstrand 15 hydrostatic with Peerless 2600 transaxle.Reference

PTO & Hydraulics

Pressure65.5 barReference

Pump flow11.4 lpmReference

Rear Type0Reference

Rear lift204 kgReference

Rear PTOindependentReference

ClutchelectricReference

Rear PTO Type540 (1.375)Reference

Rear PTO Type2000 (1.0)Reference

Front PTOindependentReference

Clutchelectro-magneticReference

Dimensions

Wheelbase139 cmReference

Weight372 kgReference

Front tire18x8.5-8Reference

Rear tire26x12-12Reference

Weight312 kgReference

Lawn/turf front18x8.5-8Reference

Lawn/turf rear26x12-12Reference

Length200 cmReference

Width113 cmReference

Height (steering wheel)129 cmReference

Height (ROPS)194 cmReference

Max rear axle816 kgReference

Ground clearance20 cmReference

Rear axle30 mmReference

Massey Ferguson 2920LC attachments

48" mid-mount mower deckReference

54" mid-mount mower deckReference

60" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

2920LC Serial Numbers

Location:Left side of tractor frame, ahead of operator platform.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps20Reference

Battery CCA500Reference

Battery volts12Reference

Attachment overview

48" mid-mount mower deckReference

54" mid-mount mower deckReference

60" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

Kwik-Way Backhoe

Backhoe typeKwik-Way BackhoeReference

Transport height215 cmReference

Bucket width22 cmReference

Bucket width30 cmReference

2-Foot flat digging depth198 cmReference

Reach from pivot312 cmReference

Loading height213 cmReference

Bucket Rotation147°Reference

Swing Arc151°Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
