Tractor · 2025Unverified
Massey Ferguson 2M.60
Massey Ferguson 2M.60 — 2M Series · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
4288 to 4674 pounds
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Iseki 2.4L 4-cyl dieselReference
Fuel tank53.0 LReference
Engine45.0 kWReference
IsekiReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke87 x 102 mmReference
Emission controlEGR, DOC and DPFReference
Power45.0 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed power shuttleReference
hydrostaticReference
Gear Ground clearance29 cmReference
Typepower shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)35.0 kWReference
Hydro PTO (claimed)33.3 kWReference
Typeopen centerReference
Gear Pump flow48.1 lpmReference
Hydro Pump flow47.7 lpmReference
Steering flow26.9 lpmReference
Rear TypeII/IReference
Gear Rear lift (at ends)1700 kgReference
Hydro Rear lift (at ends)1579 kgReference
Gear Rear lift (at 24"/610mm)1500 kgReference
Hydro Rear lift (at 24"/610mm)1399 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight4288 to 4674 poundsReference
Length341 cmReference
Width181 cmReference
Height (ROPS)261 cmReference
Height (cab)236 cmReference
ROPS Weight1945 kgReference
Cab Weight2120 kgReference
Hydro Ground clearance35 cmReference
Massey Ferguson 2M.60 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Massey Ferguson CB75 Backhoe
Backhoe typeMassey Ferguson CB75 BackhoeReference
Transport height193 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Digging depth233 cmReference
Reach from pivot304 cmReference
Loading height177 cmReference
Bucket Rotation174°Reference
Swing Arc175°Reference
Bucket force1397 kgReference
Dipperstick force914 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
