The Massey Ferguson 30 is a compact tractor model, rated at 30 hp. Manufactured from 1963 to 1964, it features a 4-cylinder diesel liquid-cooled engine, which drives through two-wheel drive and an 8-speed gearbox. The tractor's listed weight is 1360 kg, and it is suited for tasks in areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1360 kg
Catalogue coverage
Variants represented
2
Richest spec table
28 rows
Recorded power
30 hp
Recorded weight
1360 kg
Transmissions
8-speed
Production years
1963-1964
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Two-wheel driveReference
Open operator station.Reference
Engine
Perkins 1.8L 4-cyl dieselReference
Fuel tank45.4 LReference
Engine22.4 kWReference
Perkins A4.107Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke79 x 89 mmReference
Power22.4 kWReference
Rated RPM2400Reference
Torque102.0 NmReference
Torque RPM1200Reference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear lift1030 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase185 cmReference
Weight1360 kgReference
Front tire5.50-16Reference
Rear tire11.2/10-28Reference
Ag front5.50-16Reference
Ag rear11.2/10-28Reference
Length291 cmReference
Height139 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
