Massey Ferguson 302
Massey Ferguson 302 — Industrial tractor · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
4485 to 4525 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Industrial tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Open operator station.Reference
Variants
302mechanical shuttleReference
304power shuttleReference
Engine
Perkins 3.3L 4-cyl dieselReference
Continental 3.2L 4-cyl gasolineReference
Engine (gross)50.7 kWReference
Engine (net)47.0 kWReference
Drawbar (claimed)37.3 kWReference
Perkins AD4.203Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power (net)44.0 kWReference
Power (gross)48.8 kWReference
Rated RPM2200Reference
Torque225.1 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity6.6 LReference
Continental GF-193Reference
gasolineReference
Displacement3.2 LReference
Bore/Stroke95 x 111 mmReference
Power (net)47.0 kWReference
Power (gross)50.7 kWReference
Torque238.7 NmReference
Oil capacity5.7 LReference
Transmission
6-speed manual shuttleReference
Typemanual shuttleReference
Gears6 forward and reverseReference
Oil capacity30.3 LReference
Capacities
Fuel64.3 LReference
PTO & Hydraulics
Hydraulic system41.6 LReference
Typeopen centerReference
Capacity41.6 LReference
Pressure146.5 barReference
Pump flow90.8 lpmReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase203 cmReference
Weight4485 to 4525 poundsReference
Front tire9.00x16Reference
Rear tire16.9x28Reference
Industrial front9.00x16Reference
Industrial front9.00x15Reference
Industrial rear16.9x28Reference
Length322 cmReference
Width182 cmReference
Height168 cmReference
Gas Weight2034 kgReference
Diesel Weight2052 kgReference
Ground clearance39 cmReference
Front tread133 cmReference
Rear tread154 cmReference
Rear tread142 to 214 cmReference
Massey Ferguson 302 attachments
front-end loaderReference
backhoeReference
Attachment overview
Front-end loaderReference
BackhoeReference
Massey Ferguson 220 Backhoe
Backhoe typeMassey Ferguson 220 BackhoeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
