Massey Ferguson 320
Massey Ferguson 320 — Skidder · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Weight
7257 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
SkidderReference
Drive4x4 articualted 4WDReference
Final drivesplanetaryReference
Differential lockmechanical frontReference
Wet disc brakesReference
Four-post ROPS.Reference
Engine
Perkins 5.2L 4-cyl dieselReference
Fuel tank114.3 LReference
Engine (gross)64.1 kWReference
Engine (net)59.7 kWReference
PerkinsReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.2 LReference
Bore/Stroke114 x 127 mmReference
Power (net)59.7 kWReference
Power (gross)64.1 kWReference
Fuel systemdirect injectionReference
Compression16.5:1Reference
Rated RPM2000Reference
Torque330.9 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity16.6 LReference
Coolant capacity22.7 LReference
Transmission
8-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears8 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure117.2 barReference
Pump flow100.3 lpmReference
Dimensions
Wheelbase260 cmReference
Weight7257 kgReference
Front tire23.1x26Reference
Rear tire23.1x26Reference
Industrial front23.1x26Reference
Industrial rear23.1x26Reference
Industrial front18.4x24Reference
Industrial front28.1x26Reference
Industrial front18.4x34Reference
Industrial rear18.4x24Reference
Industrial rear28.1x26Reference
Industrial rear18.4x34Reference
Length551 cmReference
Width256 cmReference
Height (ROPS)279 cmReference
Shipping weight7257 kgReference
Clearance (front axle)48 cmReference
Front tread196 cmReference
Rear tread196 cmReference
Massey Ferguson 320 attachments
bladeReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Speeds
With 23.1x26 tires. Reverse speeds are 15% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
