Tractor · 1999Unverified
Massey Ferguson 3210
Massey Ferguson 3210 — Orchard/Vineyard tractor · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount folding ROPS. Cab optional with air-conditioning.Reference
Engine
Perkins 2.7L 3-cyl dieselReference
3210S Fuel tank62.8 LReference
3210GE Fuel tank45.0 LReference
Engine41.0 kWReference
Perkins 903.27Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power41.0 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Pre-heatingthermostartReference
Compression17.25:1Reference
Rated RPM2300Reference
Idle RPM750-2475Reference
Torque193.1 NmReference
Torque RPM1200Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Intake valve clearance0.203 mmReference
Exhaust valve clearance0.457 mmReference
Transmission
12-speed partially synchronizedReference
24-speed creeperReference
Typepartially synchronizedReference
Gears12 forward and reverseReference
Clutch279.4mm dry discReference
Four synchronized gears (1-4) in three ranges. Gears may be shifted on the move with the clutch. Tractor must be stopped, and clutch used, to shift range or shuttle.Reference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure170.0 barReference
Pump flow39.4 lpmReference
Pump flow50.2 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2600 kgReference
Rear PTOindependentReference
Clutchdry discReference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type540/540EReference
Engine RPM540@1944Reference
Engine RPM540E@1375Reference
Engine RPM1000@1916Reference
Dimensions
2WD Wheelbase194 cmReference
4WD Wheelbase189 cmReference
Front tire9.50-15Reference
3210S 2WD Rear tire13.6/12-24Reference
3210S 2WD Standard tires (ag)Front: 9.50-15. Rear: 13.6/12-24Reference
3210S 4WD Standard tires (ag)Front: 8.25-16. Rear: 13.6/12-24Reference
3210GE 2WD Standard tires (ag)Front: 9.00-10. Rear: 14.9LR20Reference
3210GE 4WD Standard tires (ag)Front: 9.0/75-16. Rear: 360/70R24Reference
3210F 2WD Standard tires (ag)Front: 750-15. Rear: 13.6-24Reference
3210F 4WD Standard tires (ag)Front: 280/70-18. Rear: 13.6-28Reference
Length379 cmReference
Clearance (drawbar)36 cmReference
3210S Steering wheel143 cmReference
3210GE Steering wheel137 cmReference
3210F Steering wheel143 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Battery AH95Reference
Massey Ferguson 3210 Height
3210S Hood124 cmReference
3210GE Hood123 cmReference
3210F Hood124 cmReference
ROPS234 cmReference
3210S Cab221 cmReference
3210F Cab224 cmReference
Speeds
With 13.6R-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
