Tractor · 1999Unverified
Massey Ferguson 3220
Massey Ferguson 3220 — Orchard/Vineyard tractor · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount folding ROPS. Cab optional with air-conditioning.Reference
Engine
Perkins 2.7L 3-cyl dieselReference
3220S Fuel tank62.8 LReference
3220GE Fuel tank45.0 LReference
Engine47.7 kWReference
Perkins 903.27TReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power47.7 kWReference
Air cleanerdryReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed partially synchronizedReference
24-speed creeperReference
Typepartially synchronizedReference
Gears12 forward and reverseReference
Clutch279.4mm dry discReference
Four synchronized gears (1-4) in three ranges. Gears may be shifted on the move with the clutch. Tractor must be stopped, and clutch used, to shift range or shuttle.Reference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Typeopen centerReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2600 kgReference
Rear PTOindependentReference
Clutchdry discReference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type540/540EReference
Engine RPM540@1944Reference
Engine RPM540E@1375Reference
Engine RPM1000@1916Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Battery AH95Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
