Massey Ferguson 3235

Name: Massey Ferguson 3235
Brand: Massey Ferguson

Massey Ferguson 3235 — Orchard/Vineyard tractor · 80 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

80 hp

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Orchard/Vineyard tractorReference

Two- or four-wheel driveReference

Differential lockelectro-hydraulic rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post mid-mount folding ROPS. Cab optional with air-conditioning.Reference

Engine

Perkins 4.2L 4-cyl dieselReference

3235S Fuel tank62.8 LReference

3235GE Fuel tank45.0 LReference

Engine59.7 kWReference

Perkins 1004.42Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.2 LReference

Bore/Stroke103 x 127 mmReference

Power59.7 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Pre-heatingthermostartReference

Compression18.5:1Reference

Rated RPM2200Reference

Idle RPM750-2310Reference

Torque284.1 NmReference

Torque RPM1400Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Intake valve clearance0.203 mmReference

Exhaust valve clearance0.457 mmReference

Transmission

12-speed partially synchronizedReference

24-speed creeperReference

Typepartially synchronizedReference

Gears12 forward and reverseReference

Clutch279.4mm cerametallic discReference

Four synchronized gears (1-4) in three ranges. Gears may be shifted on the move with the clutch. Tractor must be stopped, and clutch used, to shift range or shuttle.Reference

TypecreeperReference

Gears24 forward and 12 reverseReference

PTO & Hydraulics

Typeopen centerReference

Pressure170.0 barReference

Pump flow53.0 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift2600 kgReference

Rear PTOindependentReference

Clutchdry discReference

Rear PTO Type540/1000 (1.375)Reference

Rear PTO Type540/540EReference

Engine RPM540@1944Reference

Engine RPM540E@1375Reference

Engine RPM1000@1916Reference

Dimensions

2WD Wheelbase205 cmReference

4WD Wheelbase201 cmReference

Front tire7.50-16Reference

3235S Rear tire14.9R24Reference

3235S Standard tires (ag)Front: 7.50-16. Rear: 14.9R24Reference

3235S 4WD Standard tires (ag)Front: 360/60R20. Rear: 14.9R28Reference

3235GE 2WD Standard tires (ag)Front: 9.00-10. Rear: 14.9R20Reference

3235GE 4WD Standard tires (ag)Front: 280/70-16. Rear: 360/70R24Reference

3235F 2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9R24Reference

3235F 4WD Standard tires (ag)Front: 275/80-18. Rear: 16.9R24Reference

3235FA 2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9R24Reference

3235FA 4WD Standard tires (ag)Front: 300/70R20. Rear: 420/70R28Reference

Length390 cmReference

3235S Steering wheel148 cmReference

3235GE Steering wheel137 cmReference

3235F Steering wheel148 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Battery AH95Reference
