Tractor · 1999Unverified
Massey Ferguson 3255
Massey Ferguson 3255 — Orchard/Vineyard tractor · 95 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
95 hp
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount folding ROPS. Cab optional with air-conditioning.Reference
Engine
Perkins 4.0L 4-cyl dieselReference
Fuel tank45.0 LReference
Engine70.8 kWReference
Perkins 1004.40TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power70.8 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Pre-heatingthermostartReference
Compression17.25:1Reference
Rated RPM2200Reference
Idle RPM800-2354Reference
Torque387.1 NmReference
Torque RPM1400Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Intake valve clearance0.203 mmReference
Exhaust valve clearance0.457 mmReference
Transmission
12-speed partially synchronizedReference
24-speed creeperReference
Typepartially synchronizedReference
Gears12 forward and reverseReference
Clutch304.8mm cerametallic discReference
Four synchronized gears (1-4) in three ranges. Gears may be shifted on the move with the clutch. Tractor must be stopped, and clutch used, to shift range or shuttle.Reference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure170.0 barReference
Pump flow53.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2600 kgReference
Rear PTOindependentReference
Clutchdry discReference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type540/540EReference
Engine RPM540@1944Reference
Engine RPM540E@1375Reference
Engine RPM1000@1916Reference
Dimensions
2WD Wheelbase217 cmReference
4WD Wheelbase213 cmReference
Front tire9.00-10Reference
3255GE 2WD Rear tire14.9LR20Reference
3255GE 2WD Standard tires (ag)Front: 9.00-10. Rear: 14.9LR20Reference
3255GE 4WD Standard tires (ag)Front: 9.0/75-16. Rear: 14.9LR20Reference
3255FA 4WD Standard tires (ag)Front: 300/70R20. Rear: 420/70R28Reference
Length404 cmReference
3255GE Steering wheel137 cmReference
3255FA Steering wheel148 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Battery AH95Reference
Massey Ferguson 3255 Height
3255GE Hood123 cmReference
3255FA Hood128 cmReference
3255GE ROPS234 cmReference
3255FA ROPS259 cmReference
3255FA Cab228 cmReference
Speeds
With 14.9R28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
