Industrial Tractor · Unverified
Massey Ferguson 33
Massey Ferguson 33 — Wheel Loader · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
14950 to 15300 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Wheel LoaderReference
Drive4x4 4WDReference
Final drivesplanetaryReference
SteeringpowerReference
Steeringpower four-wheelReference
Pneumatic-hydraulic drum brakesReference
Open operator station. Four-post ROPS available.Reference
Engine
Perkins 4.1L 4-cyl dieselReference
Engine (net)55.2 kWReference
Perkins A4.248Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke101 x 127 mmReference
Power (net)55.2 kWReference
Air cleanerdryReference
Rated RPM2300Reference
Torque355.3 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity7.6 LReference
Coolant capacity14.2 LReference
Transmission
4-speed power shiftReference
Typepower shiftReference
Gears4 forward and reverseReference
Capacities
Fuel140.0 LReference
PTO & Hydraulics
Hydraulic system64.3 LReference
Typeopen centerReference
Capacity64.3 LReference
Pressure137.9 barReference
Pump flow132.5 lpmReference
Dimensions
Wheelbase212 cmReference
Weight14950 to 15300 poundsReference
Front tire14.00-24Reference
Rear tire14.00-24Reference
Industrial front14.00-24Reference
Industrial rear14.00-24Reference
Industrial front13.00-24Reference
Industrial front15.5-25Reference
Industrial rear13.00-24Reference
Industrial rear15.5-25Reference
Length539 cmReference
Width220 cmReference
Height (steering wheel)226 cmReference
Height (cab)292 cmReference
Shipping weight6781 kgReference
Operating weight6940 kgReference
Ground clearance40 cmReference
Front tread179 cmReference
Rear tread160 cmReference
Massey Ferguson 33 attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Charging amps32Reference
Batteries2Reference
Battery volts12Reference
Battery AH95Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
