The Massey Ferguson 3305 is a compact industrial tractor, with a rated output of 56 hp. It was manufactured from 1966 to 1972 and features a 4-cylinder diesel liquid-cooled engine, coupled with a 4-speed gearbox and two-wheel drive. The listed weight of the 3305 is 2143 kg, making it suitable for tasks covering approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
56 hp
Weight
2143 kg
Catalogue coverage
Variants represented
2
Richest spec table
62 rows
Recorded power
56 hp
Recorded weight
2143 kg
Transmissions
4-speed torque converter
Production years
1966-1972
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Industrial tractorReference
Two-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Disc brakesReference
Open operator station.Reference
Variants
3303gear transmissionReference
3305torque converterReference
Engine
Perkins 3.3L 4-cyl dieselReference
Perkins 3.5L 4-cyl dieselReference
Engine44.7 kWReference
Drawbar (claimed)39.5 kWReference
Perkins AD4.203Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power42.5 kWReference
Rated RPM2000Reference
Torque225.1 NmReference
Torque RPM1260Reference
StarterelectricReference
Starter volts12Reference
Perkins A4.212Reference
Displacement3.5 LReference
Bore/Stroke98 x 114 mmReference
Power44.7 kWReference
Transmission
4-speed torque converterReference
TransmissionInstant ReverseReference
Typetorque converterReference
Gears4 forward and reverseReference
ClutchhydraulicReference
PTO & Hydraulics
PTO (claimed)41.5 kWReference
Typeopen centerReference
Pump flow16.3 lpmReference
Pump flow98.0 lpmReference
Steering flow21.2 lpmReference
Rear TypeIReference
Rear lift1519 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1685Reference
Dimensions
Wheelbase207 cmReference
Weight2143 kgReference
Front tire9.00-16Reference
Rear tire16.9/24-28Reference
Industrial front9.00-16Reference
Industrial rear16.9/24-28Reference
Length325 cmReference
Width208 cmReference
Height (steering wheel)167 cmReference
Ground clearance40 cmReference
Front tread142 cmReference
Rear tread154 cmReference
Massey Ferguson 3305 attachments
front-end loaderReference
backhoeReference
Attachment overview
Front-end loaderReference
BackhoeReference
Massey Ferguson 252 Backhoe
Backhoe typeMassey Ferguson 252 BackhoeReference
Speeds
With 16.9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
