Tractor · 2021Unverified
Massey Ferguson 3306
Massey Ferguson 3306 — Orchard/Vineyard tractor · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Two-post mid-mount folding ROPS. Cab optional with air-conditioning.Reference
Engine
AGCO Power 3.3L 3-cyl dieselReference
Fuel tank85.2 LReference
Engine50.0 kWReference
AGCO Power 33 CWIC3Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke108 x 120 mmReference
Power50.0 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Pressure180.0 barReference
Pump flow42.0 lpmReference
Pump flow59.0 lpmReference
Steering flow31.0 lpmReference
ControlII/IReference
Rear lift2100 kgReference
Rear PTOindependentReference
Clutchmechanical discReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1900Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
