Tractor · 1988Unverified
Massey Ferguson 340
Massey Ferguson 340 — 300 Series · 41 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
2370 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in Coventry, EnglandReference
Four-wheel driveReference
Final drivesbevel gearReference
Power steeringReference
Hydraulic drum brakesReference
Trailer brakeshydraulicReference
Cab standard.Reference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank68.1 LReference
Engine34.3 kWReference
Perkins AD3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power34.3 kWReference
Fuel systemdirect injectionReference
Air cleanerdry elementReference
Compression16:1Reference
Rated RPM2500Reference
Idle RPM750-2470Reference
Torque170.9 NmReference
Torque RPM1300Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity9.8 LReference
Oil capacity6.8 LReference
Oil change250 hReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)30.6 kWReference
Typeopen centerReference
Pump flow34.8 lpmReference
Pump flow17.0 lpmReference
Total flow51.9 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2145 kgReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase217 cmReference
Weight2370 kgReference
Front tire10.5/80-18Reference
Rear tire14.9/13-24Reference
Standard tires (ag)Front: 10.5/80-18. Rear: 14.9/13-24Reference
Optional tires (ag)Front: 8.3-24. Rear: 12.4/11-32Reference
Length325 cmReference
Width180 cmReference
Height (cab)215 cmReference
Front tread121 to 182 cmReference
Rear tread142 to 213 cmReference
2370 kgReference
Max front axle3928 kgReference
Max rear axle4542 kgReference
340 Serial Number Location
Serial number plate on the right side of the tractor, near the brake pedals.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery CCA420Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
