Tractor · 2005Unverified

Massey Ferguson 3435

Name: Massey Ferguson 3435
Brand: Massey Ferguson

Massey Ferguson 3435 — Orchard/Vineyard tractor · 72 hp. Reference specifications; pending source verification.

The Massey Ferguson 3435 tractor model has a rated power of 72 hp, placing it in the mid-range of its class. Manufactured from 2005 to 2010, this tractor features a 4-cylinder diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

72 hp

Max power

80 hp

Catalogue coverage

Variants represented

Richest spec table

100 rows

Recorded power

72 hp

Transmissions

20-speed

Production years

2005-2010

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Orchard/Vineyard tractorReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Two-post mid-mount foldable ROPS. Cab optional.Reference

Variants

3435Vnarrow vineyard modelReference

3435SstandardReference

3435FfruitReference

3435GEground effect low-profile modelReference

Engine

Perkins 4.4L 4-cyl dieselReference

Fuel tank73.1 LReference

Engine59.7 kWReference

Perkins 1104C-44Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

EmissionsTier IIReference

Power59.7 kWReference

Air cleanerdual dry elementReference

Rated RPM2200Reference

Torque79.3 NmReference

Torque RPM2200Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,200 RPMReference

Emissions complianceTier IIReference

Engine torque at rated speed26.5 kgReference

Cooling systemliquid-cooledReference

Transmission

20-speedReference

30-speedReference

TransmissionSynchronozed shuttleReference

Gears20 forward and 10 reverseReference

Optional transmission.Reference

TransmissionSynch shuttle with creeperReference

Gears30 forward and 15 reverseReference

Transmission TypeSync ShuttleReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)53.7 kWReference

Pressure180.0 barReference

Valves2 to 3 rearReference

Valves2 mid optionalReference

Pump flow51.9 lpmReference

Pump flow62.1 lpmReference

Steering flow25.0 lpmReference

Rear Type1/2Reference

Rear lift (at ends)2600 kgReference

Rear lift (at 24"/610mm)1599 kgReference

Rear PTO Type540/540E/1000Reference

Dimensions

Wheelbase210 cmReference

Wheelbase215 cmReference

Front tire6.50-16Reference

Rear tire11.2R28Reference

Ag front6.50-16 (V)Reference

Ag front7.50R16 (S)Reference

Ag front280/70R16 (F)Reference

Ag front240/70R16 (GE)Reference

Ag rear11.2R28 (V)Reference

Ag rear12.4R28 (S)Reference

Ag rear380/70R24 (F)Reference

Ag rear380/70R20 (GE)Reference

Length375 cmReference

Width110 cmReference

Width119 cmReference

Width127 cmReference

Width143 cmReference

Massey Ferguson 3435 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Massey Ferguson 3435 Height

216 cmReference

213 cmReference

119 cmReference

203 cmReference

206 cmReference

General

Make & ModelMassey FergusonReference

Rollover protective structureTwo-post mid-mount foldable ROPS.Reference

Capacities

Capacity268.5 ciReference

Power

Max Power80 hpReference

PTO

PTO Power72 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typehydrostatic powerReference

Hydraulics

Maximum operating pressure2,610 psiReference

Remote Valves2 to 3 rear | 2 mid optional valvesReference

Steering & Implements flow6.6 gpm (16.4 gpm)Reference

Rear Hitch category (SAE designation)Category 1/2Reference

Rear Hitch maximum lift capacity2,600 kgReference

Dimensions & weight

Height Over Cab213.6 cmReference

Height Over ROPS216.9 cmReference

Overall Height119.9 cmReference

Overall Length375 cmReference

Overall Width143.3 cmReference

Wheels & tyres

Rear Wheel Type11.2R28Reference

Front Wheel Type6.50-16Reference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
