Tractor · 1960Unverified
Massey Ferguson 35
Massey Ferguson 35 — Utility tractor · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Max power
24.0 kW
Weight
2982 to 3559 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in Detroit, Michigan, USAReference
Original price was $2,529 in 1963Reference
The gasoline engine was available after 1961.Reference
Two-wheel driveReference
Differential lockmechanical rearReference
Steeringmanual recirculating ballReference
Independent manual shoe/drum brakesReference
Open operator station.Reference
Variants
35ag tractorReference
35 UtilityindustrialReference
35 Turflow-profileReference
Engine
Perkins 2.5L 3-cyl dieselReference
Continental 2.2L 4-cyl gasolineReference
Plows3Reference
Drawbar (tested)24.0 kWReference
Perkins 3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Air cleanerdryReference
Compression17.4:1Reference
Rated RPM2000Reference
Idle RPM700-2150Reference
Firing order1-2-3Reference
Starter volts12Reference
Oil capacity5.7 LReference
ContinentalReference
gasolineReference
4-cylinderReference
liquid-cooled OHVReference
Displacement2.2 LReference
Bore/Stroke84 x 98 mmReference
Compression6.6:1Reference
Rated RPM2200Reference
Idle RPM450-2250Reference
Firing order1-3-4-2Reference
Coolant capacity9.5 LReference
Sparkplug18mmReference
Sparkplug gap0.635 mmReference
Intake valve clearance0.330 mmReference
Exhaust valve clearance0.330 mmReference
Oil change100 hReference
Power at rated engine speed27.6 kWReference
Max power24.0 kWReference
Transmission
6-speed gearReference
12-speed partial power shiftReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity30.3 LReference
Oil typeSAE 80 GL1Reference
TransmissionMulti-PowerReference
Typepartial power shiftReference
Gears12 forward and 4 reverseReference
Multi-Power adds a Low-High power shift to the basic transmission. The transmission will free-wheel in Multi-Power low, it must be set to high for engine braking.Reference
PTO & Hydraulics
PTO (tested)27.6 kWReference
Hydraulic system30.3 LReference
Capacity30.3 LReference
Pressure193.1 barReference
Pump flow13.2 lpmReference
Rear TypeIReference
Rear PTOtransmissionReference
Rear PTOtwo-stage clutchReference
Rear PTO Typeground/540 (1.375)Reference
Engine RPM540@1700Reference
Power at rated PTO speed22.3 kWReference
Capacities
Fuel52.6 LReference
Dimensions
Wheelbase182 cmReference
Weight2982 to 3559 poundsReference
Front tire5.50-16Reference
Rear tire10-28Reference
Ag front5.50-16Reference
Ag front6.00-16Reference
Ag rear10-28Reference
Ag rear11-28Reference
Ag rear13-24Reference
Length297 cmReference
Width161 cmReference
Height137 cmReference
Clearance (front axle)52 cmReference
Front tread121 to 203 cmReference
Rear tread121 to 193 cmReference
Gas Shipping1352 kgReference
Diesel Operating1614 kgReference
Ballasted2680 kgReference
Massey Ferguson 35 attachments
front-end loaderReference
35 Serial Number Location
Serial number plate on the dashboard of the Massey Ferguson 35.Reference
35 Serial Numbers
1960204181Reference
1961211071Reference
1962222207Reference
1963235123Reference
1964247605Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemgeneratorReference
Charging amps12Reference
Battery volts12Reference
Gas Battery AH40Reference
Diesel Battery AH96Reference
Test results
Diesel 6-speed 2WDMay 16 - 23, 1960Link: Nebraska Tractor Test 744 fileReference
PTO performanceReference
Fuel use9.1 l/hourReference
Fuel use7.2 l/hourReference
Drawbar performanceReference
Fuel use8.7 l/hourReference
Gear 4 used for power test.Reference
Max pull1798 kgReference
Gear 2 used for pull test.Reference
Speeds
With 11-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
