Industrial Tractor · 1962Unverified

Massey Ferguson 35 Turf

Name: Massey Ferguson 35 Turf
Brand: Massey Ferguson

Massey Ferguson 35 Turf — low-profile tractor · 47 hp. Reference specifications; pending source verification.

The Massey Ferguson 35 Turf is a compact industrial tractor with a rated output of 47 hp, produced from 1962 to 1964. It features a 4-cylinder diesel liquid-cooled engine powering a two-wheel drive system with a 6-speed gearbox. The listed weight of the tractor ranges from 2950 to 3000 pounds. It is designed for use on small areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Weight

2950 to 3000 pounds

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

47 hp

Recorded weight

1338 kg

Transmissions

6-speed gear

Production years

1962-1964

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

low-profile tractorReference

Two-wheel driveReference

SteeringmanualReference

SteeringpowerReference

Open operator station.Reference

Variants

35ag tractorReference

35 UtilityindustrialReference

35 Turflow-profileReference

Engine

Continental 2.2L 4-cyl gasolineReference

Perkins 2.5L 3-cyl dieselReference

Gas Fuel tank52.6 LReference

Diesel Fuel tank40.5 LReference

Engine (gross)35.0 kWReference

ContinentalReference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke84 x 98 mmReference

Power (gross)33.9 kWReference

Rated RPM2200Reference

Torque161.4 NmReference

Torque RPM1200Reference

StarterelectricReference

Starter volts12Reference

Oil capacity4.7 LReference

Coolant capacity9.5 LReference

Perkins 3.152Reference

dieselReference

3-cylinderReference

Displacement2.5 LReference

Bore/Stroke91 x 127 mmReference

Power (gross)35.0 kWReference

Torque169.5 NmReference

Oil capacity5.7 LReference

Coolant capacity9.3 LReference

Transmission

6-speed gearReference

6-speed mechanical shuttleReference

TypegearReference

Gears6 forward and 2 reverseReference

Clutchdry discReference

Oil capacity30.3 LReference

Typemechanical shuttleReference

Gears6 forward and reverseReference

PTO & Hydraulics

Rear PTOtransmissionReference

Rear PTOliveReference

Rear PTO Type540Reference

Dimensions

Wheelbase182 cmReference

Weight2950 to 3000 poundsReference

Front tire9.00x8Reference

Rear tire8x24Reference

Lawn/turf front750x10Reference

Lawn/turf rear18.4/15-16Reference

Industrial front9.00x8Reference

Industrial rear8x24 (duals)Reference

Length274 cmReference

Width200 cmReference

Height124 cmReference

Gas Shipping weight1338 kgReference

Diesel Shipping weight1360 kgReference

Ground clearance19 cmReference

Rear tread180 cmReference

Speeds

With 18.4/15-16 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
