Tractor · 1983Unverified
Massey Ferguson 3525
Massey Ferguson 3525 — Row-Crop tractor · 108 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
108 hp
Max power
67.2 kW
Weight
5942 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Row-Crop tractorReference
Built in FranceReference
Original price$42,100 (1987)Reference
Two- or four-wheel driveReference
Differential lockhydraulicReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Cab standard with air-conditioning. Optional four-post ROPS canopy.Reference
Engine
Perkins 5.8L 6-cyl dieselReference
Engine96.9 kWReference
Drawbar (tested)67.2 kWReference
PerkinsReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.8 LReference
Bore/Stroke98 x 127 mmReference
Power96.9 kWReference
Air cleanerdual paper elementsReference
Compression15.5:1Reference
Rated RPM2400Reference
Starter volts12Reference
Power at rated engine speed80.5 kWReference
Max power67.2 kWReference
Transmission
16-speed partial power shiftReference
Typepartial power shiftReference
Gears16 forward and 12 reverseReference
Four gears (1-4) in two ranges (low/high) plus two-speed push-button power shift. Manual shuttle. Shifts within range are synchronized.Reference
PTO & Hydraulics
PTO (claimed)78.3 kWReference
PTO (tested)80.5 kWReference
Typeopen centerReference
Pressure175.1 barReference
Valves2 or 3Reference
Pump flow56.8 lpmReference
Total flow111.7 lpmReference
Total flow54.9 lpmReference
Total flow56.8 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)3452 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed77.3 kWReference
Dimensions
Wheelbase271 cmReference
Weight5942 kgReference
Front tire10.00-16Reference
Rear tire18.4-38Reference
Ag front10.00-16Reference
Ag rear18.4-38Reference
Length469 cmReference
Width238 cmReference
Width299 cmReference
Operating weight5942 kgReference
Ballasted weight6642 kgReference
Rear axle82 mmReference
Front tread154 to 215 cmReference
Front tread160 to 205 cmReference
Rear tread152 to 248 cmReference
Rear tread152 to 314 cmReference
Massey Ferguson 3525 attachments
front-end loaderReference
3525 Serial Numbers
Location:Instrument panel on rightReference
1983K241213Reference
1984T101201Reference
1985L101201Reference
1986U031201Reference
1987V001201Reference
FAQ: How to read a serial number table.Reference
Attachment overview
Massey Ferguson 246 loaderReference
Massey Ferguson 856 loaderReference
Test results
Diesel 16-speed 4WDApril 17 - May 1, 1984Link: Nebraska Tractor Test 1512 fileReference
PTO performanceReference
Fuel use26.5 l/hourReference
Fuel use23.5 l/hourReference
Drawbar performanceReference
Gear 10 used for power test.Reference
Max pull4228 kgReference
Gear 7 used for pull test.Reference
Speeds
With 18.4x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
