Tractor · 1994Unverified
Massey Ferguson 354GE
Massey Ferguson 354GE — 304 Specialty Series · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
4740 to 4961 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Original price was $30,500 in 1999Reference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount folding ROPS.Reference
Variants
354SnarrowReference
354GElow-profileReference
354Vultra-narrowReference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank45.4 LReference
Perkins AD3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Air cleanerdryReference
Rated RPM2250Reference
Starter volts12Reference
Transmission
12-speed synchroReference
12-speed shuttleReference
24-speed creeperReference
TypesynchroReference
Gears12 forward and 4 reverseReference
Clutch279mm dry discReference
TypeshuttleReference
Gears12 forward and reverseReference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)31.3 kWReference
Rear valves2Reference
Front valves3Reference
Pump flow43.1 lpmReference
Pump flow54.1 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Engine RPM540@2000Reference
Dimensions
2WD Wheelbase195 cmReference
4WD Wheelbase189 cmReference
Weight4740 to 4961 poundsReference
Front tire9.00-10Reference
2WD Rear tire14.9LR20Reference
2WD Standard tires (ag)Front: 9.00-10. Rear: 14.9LR20Reference
4WD Standard tires (ag)Front: 9.0/75-16. Rear: 14.9LR20Reference
Length332 cmReference
Width137 cmReference
Height (steering wheel)137 cmReference
Height (hood)123 cmReference
2WD Weight2150 kgReference
4WD Weight2250 kgReference
Clearance (drawbar)36 cmReference
2WD Front tread108 to 129 cmReference
4WD Front tread107 to 137 cmReference
Rear tread99 to 129 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
