Tractor · 1994Unverified
Massey Ferguson 354S
Massey Ferguson 354S — 304 Specialty Series · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
4761 to 5027 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Original price was $23,700 in 1999Reference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount folding ROPS. Cab optional.Reference
Variants
354SnarrowReference
354GElow-profileReference
354Vultra-narrowReference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank53.0 LReference
Perkins AD3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Air cleanerdryReference
Rated RPM2250Reference
Starter volts12Reference
Transmission
12-speed synchroReference
12-speed shuttleReference
24-speed creeperReference
TypesynchroReference
Gears12 forward and 4 reverseReference
Clutch279mm dry discReference
TypeshuttleReference
Gears12 forward and reverseReference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)31.3 kWReference
Rear valves2Reference
Front valves3Reference
Pump flow43.1 lpmReference
Pump flow54.1 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Engine RPM540@2000Reference
Dimensions
2WD Wheelbase195 cmReference
4WD Wheelbase189 cmReference
Weight4761 to 5027 poundsReference
Front tire6.00-16Reference
2WD Rear tire13.6-24Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 13.6-24Reference
4WD Standard tires (ag)Front: 8.25-16. Rear: 13.6-24Reference
Length323 cmReference
Width133 cmReference
2WD Weight2159 kgReference
4WD Weight2280 kgReference
Clearance (drawbar)34 cmReference
2WD Front tread108 to 148 cmReference
4WD Front tread107 to 137 cmReference
Rear tread98 to 152 cmReference
Steering wheel138 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Massey Ferguson 354S Height
Hood124 cmReference
Cab219 cmReference
Speeds
With 13.6-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
