Tractor · 1962Unverified
Massey Ferguson 35X
Massey Ferguson 35X — Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
1497 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in Coventry, EnglandReference
Two-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank38.6 LReference
Engine33.2 kWReference
Perkins A3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power33.2 kWReference
Fuel systemindirect injectionReference
Air cleaneroil bathReference
Compression17.4:1Reference
Rated RPM2250Reference
Idle RPM500-2375Reference
Torque161.4 NmReference
Torque RPM1300Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
12-speed partial power shiftReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch279.4mm dry discReference
Oil capacity30.3 LReference
TransmissionMulti-PowerReference
Typepartial power shiftReference
Gears12 forward and 4 reverseReference
Multi-Power adds a Low-High power shift to the basic transmission. The transmission will free-wheel in Multi-Power low, it must be set to high for engine braking.Reference
PTO & Hydraulics
Typeopen centerReference
Pressure137.9 barReference
Pump flow14.0 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift1134 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1500Reference
Engine RPM540@1700Reference
Dimensions
Weight1497 kgReference
Front tire6.00-16Reference
Rear tire12.4/11-28Reference
Ag front6.00-16Reference
Ag rear12.4/11-28Reference
Ag front4.00-19Reference
Ag rear10-28Reference
Length297 cmReference
Width162 cmReference
Height (steering wheel)137 cmReference
Height (exhaust)201 cmReference
Operating weight1497 kgReference
Ballasted weight3302 kgReference
Clearance (rear axle)32 cmReference
Front tread121 to 203 cmReference
Rear tread121 to 193 cmReference
35X Serial Numbers
Location:Serial number plate on the instrument panel.Reference
1962302413Reference
1963307231Reference
1964352255Reference
FAQ: How to read a serial number table.Reference
Speeds
With 11-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
