The Massey Ferguson 363 is a tractor model with a rating of approximately 58 hp, situated at the lighter end of its class. It was produced between 1987 and 1994. Equipped with a 3-cylinder turbocharged diesel liquid-cooled engine, it features four-wheel drive and a 24-speed gearbox. Its operating weight ranges from 5733 to 6361 pounds, suitable for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
58 hp
Weight
5733 to 6361 pounds
Catalogue coverage
Variants represented
2
Richest spec table
51 rows
Recorded power
58 hp
Transmissions
24-speed
Production years
1987-1994
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in ItalyReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Cab optional.Reference
Variants
6070similar Landini modelReference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank79.9 LReference
Engine43.0 kWReference
Perkins AD3.152.4Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power43.0 kWReference
Rated RPM2250Reference
Torque208.0 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and 12 reverseReference
Clutch279mm mechanical dry discReference
PTO & Hydraulics
Total flow37.1 lpmReference
Rear lift2400 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1944Reference
Engine RPM750@1934Reference
Dimensions
2WD Wheelbase210 cmReference
4WD Wheelbase212 cmReference
Weight5733 to 6361 poundsReference
Front tire7.50-18Reference
Rear tire14.9-30Reference
Ag front7.50-18Reference
Ag rear14.9-30Reference
Ag front12.4-24Reference
Length357 cmReference
Width180 cmReference
Height224 cmReference
Rear tread130 to 189 cmReference
2600 kgReference
2885 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Capacities
Max capacity3999 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
