Tractor · 2011Unverified

Massey Ferguson 3640A

Name: Massey Ferguson 3640A
Brand: Massey Ferguson

Massey Ferguson 3640A — Utility tractor · 84 hp. Reference specifications; pending source verification.

The Massey Ferguson 3640A is a tractor with an 84 hp rated output, positioning it centrally within its class for power. Produced in 2011, this model is equipped with a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive via a hydrostatic transmission. Its listed weight ranges from 6239 to 7187 pounds, making it suitable for tasks involving approximately up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

84 hp

Max power

84 hp

Weight

6239 to 7187 pounds

Catalogue coverage

Variants represented

Richest spec table

108 rows

Recorded power

84 hp

Recorded weight

2830 kg

Transmissions

12-speed mechanical shuttle

Production years

2011-2011

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Utility tractorReference

Two- or four-wheel driveReference

Differential lockelectro-hydraulic rearReference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Two-post ROPS. Cab available with air-condtioning.Reference

Variants

3640AstandardReference

3640FflexReference

3640SspecialReference

3640VvineyardReference

3640GEground effectReference

Engine

AGCO Power 3.3L 3-cyl dieselReference

ROPS Fuel tank82.9 LReference

Cab Fuel tank110.1 LReference

Engine (gross)62.6 kWReference

AGCO Power 33CTAReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke108 x 120 mmReference

Power (gross)62.6 kWReference

Fuel systemcommon rail direct injectionReference

Air cleanerdual dry elementReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,200 RPMReference

Bore and stroke4.252x4.724 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speed mechanical shuttleReference

24-speed mechanical shuttleReference

24-speed power shuttleReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

Four synchronized gears in three ranges with mechanical shuttle. Also available as a 24-speed with mechanical high-low range.Reference

TransmissionSpeedShiftReference

Gears24 forward and reverseReference

Four gears in three ranges with two-speed power shift and mechanical shuttle.Reference

Typepower shuttleReference

Gears24 forward and 12 reverseReference

Clutchelectro-hydraulic wet discsReference

Four gears in three ranges with two-speed power shift and power shuttle.Reference

Transmission TypeMechanical ShuttleReference

Wheel Drive4WDReference

PTO & Hydraulics

Pressure190.0 barReference

Rear valves1 to 3Reference

Mid valves2Reference

Pump flow62.1 lpmReference

Rear TypeII/IReference

Controlposition and top-link draft controlReference

Rear lift (at ends)2500 kgReference

Rear lift (at ends)3000 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@1938Reference

Engine RPM1000@1962Reference

Dimensions

Wheelbase208 cmReference

Weight6239 to 7187 poundsReference

Front tire7.50-16Reference

2WD Rear tire16.9R30Reference

2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9R30Reference

4WD Standard tires (ag)Front: 11.2R24. Rear: 16.9R30Reference

Length374 cmReference

Width165 cmReference

Height (cab)250 cmReference

4WD ROPS Weight2830 kgReference

4WD Cab Weight3260 kgReference

2WD Front tread143 to 206 cmReference

4WD Front tread131 to 193 cmReference

Rear tread150 to 190 cmReference

Massey Ferguson 3640A attachments

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Massey Ferguson 906 loaderReference

Massey Ferguson 916 loaderReference

General

Make & ModelMassey FergusonReference

SCV controljoystickReference

Rollover protective structureTwo-post ROPS.Reference

Capacities

Capacity201 ciReference

Fuel tank110.2 LReference

Power

Max Power84 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Engine Speed on Rear PTO speed1,000@1,962 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typehydrostatic powerReference

Hydraulics

Maximum operating pressure2,756 psiReference

Remote Valves1 to 3 ValvesReference

Rear Hitch category (SAE designation)Category II/IReference

Rear Hitch maximum lift capacity3,000.1 kgReference

Rear Hitch Sensing Typeposition and top-link draft controlReference

Dimensions & weight

Height Over Cab251 cmReference

Overall Length374.1 cmReference

Overall Width165.1 cmReference

Overall weight2,830 kgReference

Wheels & tyres

Rear Wheel Type16.9R30Reference

Rear wheel tread range59.2 to 75 inchesReference

Front Wheel Type7.50-16Reference

Front Wheel tread range56.5 to 81.4 inchesReference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
