Tractor · 1994Unverified
Massey Ferguson 364V
Massey Ferguson 364V — 304 Specialty Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2640 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Original price was $31,000 in 1999Reference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount ROPS. Cab available.Reference
Variants
364SnarrowReference
364GElow-profileReference
364Vultra-narrowReference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank53.0 LReference
Perkins AT3.152Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Air cleanerdryReference
Rated RPM2250Reference
Starter volts12Reference
Transmission
12-speed shuttleReference
24-speed creeperReference
TypeshuttleReference
Gears12 forward and reverseReference
Clutch279mm dry discReference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)37.3 kWReference
Rear valves2 to 5Reference
Pump flow38.2 lpmReference
Pump flow51.9 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Engine RPM540@2000Reference
Dimensions
2WD Wheelbase204 cmReference
4WD Wheelbase189 cmReference
Weight2640 kgReference
Front tire6.00-16Reference
2WD Rear tire13.6R24Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 13.6R24Reference
4WD Standard tires (ag)Front: 260-70R16. Rear: 13.6R24Reference
Length362 cmReference
Width122 cmReference
2WD Clearance (drawbar)39 cmReference
4WD Clearance (drawbar)34 cmReference
2WD Front tread99 to 121 cmReference
4WD Front tread89 to 117 cmReference
Rear tread87 to 99 cmReference
Steering wheel140 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Massey Ferguson 364V Height
Hood128 cmReference
Cab225 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
