Tractor · 1962Unverified
Massey Ferguson 37
Massey Ferguson 37 — Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
1441 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Two-wheel driveReference
Open operator station.Reference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank38.6 LReference
Engine33.2 kWReference
Perkins A3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power33.2 kWReference
Compression17.4:1Reference
Rated RPM2150Reference
Idle RPM600-2300Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity10.2 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Oil capacity30.0 LReference
Three gears (1-3) plus reverse (R) in two ranges (low/high).Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight1441 kgReference
Front tire6.00-16Reference
Rear tire10-28Reference
Ag front6.00-16Reference
Ag rear10-28Reference
Ag rear11-28Reference
Length299 cmReference
Width162 cmReference
Height137 cmReference
Ground clearance32 cmReference
37 Serial Number Location
Serial number plate on the lower-right portion of the dash.Reference
Speeds
With 11-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
