Tractor · 2017Unverified
Massey Ferguson 3707F
Massey Ferguson 3707F — Orchard/Vineyard tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Orchard/Vineyard tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Two-post mid-mount folding ROPS. Cab available with optional air-conditioning.Reference
Variants
3707FfruitReference
3707WFwide fruitReference
3707SspecialReference
3707GEground effectsReference
Engine
3.4L 4-cyl dieselReference
Fuel tank74.2 LReference
Fuel tank54.1 LReference
Fuel tank104.1 LReference
Engine (max)55.9 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
EmissionsStage 3BReference
Maximum Power (gross)55.9 kWReference
Fuel systemcommon rail injectionReference
Air cleanerdual dry elementReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
24-speed mechanical shuttleReference
24-speedReference
24-speed power shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Gears24 forward and reverseReference
TransmissionSpeedshiftReference
Typepower shuttleReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Valves2 to 4Reference
Pump flow65.9 lpmReference
Pump flow26.9 lpmReference
Total flow93.1 lpmReference
Total flow120.0 lpmReference
Steering flow26.9 lpmReference
Rear TypeII/IReference
Controltop-link draft sensingReference
Rear lift (at ends)2500 kgReference
Rear lift (at ends)3000 kgReference
Front HitchIIReference
Front lift (at ends)1650 kgReference
Rear PTOindependentReference
ClutchelectrohydraulicReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Front PTO Type540EReference
Front PTO Type1000Reference
Dimensions
Wheelbase212 cmReference
Wheelbase208 cmReference
Wheelbase214 cmReference
Length398 cmReference
Width145 cmReference
Width130 cmReference
Width100 cmReference
Clearance (front axle)25 cmReference
Clearance (rear axle)24 cmReference
Steering wheel81 cmReference
Steering wheel77 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Massey Ferguson 3707F Height
ROPS188 cmReference
Cab171 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
