Tractor · 1987Unverified
Massey Ferguson 383
Massey Ferguson 383 — Model year 1987-19881989-1997 · 69 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
69 hp
Weight
6331 to 7552 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in Coventry, EnglandReference
Original price was $27300 in 1997Reference
Two-wheel driveReference
Power steeringReference
Differental wet disc brakesReference
Two-post fixed ROPS. Cab optional with air-conditioning.Reference
Engine
Perkins 4.1L 4-cyl dieselReference
Fuel tank107.9 LReference
Engine56.7 kWReference
Perkins A4.248Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke101 x 127 mmReference
Power56.7 kWReference
Fuel systemdirect injectionReference
Air cleanerdual dry elementReference
Compression16:1Reference
Rated RPM2200Reference
Idle RPM750-2380Reference
Torque279.3 NmReference
Torque RPM1400Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity15.1 LReference
Oil capacity7.5 LReference
Oil change250 hReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Four speeds in two ranges.Reference
PTO & Hydraulics
PTO (claimed)51.5 kWReference
Typeopen centerReference
Pressure206.8 barReference
Valves2Reference
Pump flow36.0 lpmReference
Pump flow16.7 lpmReference
Total flow52.6 lpmReference
Total flow63.6 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1927 kgReference
Rear lift (at ends)2453 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase213 cmReference
Weight6331 to 7552 poundsReference
Front tire7.50-16Reference
Rear tire18.4/15-30Reference
Standard tires (ag)Front: 7.50-16. Rear: 18.4/15-30Reference
Length366 cmReference
Width200 cmReference
Clearance (front axle)53 cmReference
Clearance (drawbar)35 cmReference
2WD ROPS2871 kgReference
4WD ROPS3152 kgReference
2WD Cab3155 kgReference
4WD Cab3425 kgReference
Steering wheel178 cmReference
Massey Ferguson 383 attachments
front-end loaderReference
383 Serial Number Location
Serial number plate on the right side of the tractor, near the brake pedals.Reference
383 Serial Numbers
1987V01001Reference
1988N01001Reference
1989P01001Reference
1990R01001Reference
1991S01001Reference
1992A01001Reference
1993B01001Reference
1994C01001Reference
1995D01001Reference
1996E01001Reference
1997F01001Reference
1998G01001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery CCA420 (2x)Reference
Battery CCA540 (1x)Reference
Battery volts12Reference
Attachment overview
Massey Ferguson 236 loaderReference
Massey Ferguson 832 loaderReference
Massey Ferguson 383 Height
ROPS252 cmReference
Exhaust248 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
