Tractor · 1994Unverified
Massey Ferguson 384HC
Massey Ferguson 384HC — 304 Specialty Series · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
6168 to 6796 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
High-Clearance tractorReference
Built in ItalyReference
Original price was $27,300 in 1999Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS.Reference
Variants
384SnarrowReference
384GElow profileReference
384Vultra-narrowReference
384HChigh clearanceReference
Engine
Perkins 3.9L 4-cyl dieselReference
Fuel tank79.5 LReference
Perkins A4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Air cleanerdryReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
12-speed shuttleReference
24-speed creeperReference
TypeshuttleReference
Gears12 forward and reverseReference
Clutch305mm dry discReference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
Rear valves2 to 3Reference
Pump flow54.1 lpmReference
Rear TypeIIReference
Rear lift (at ends)3851 kgReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Engine RPM540@1960Reference
Dimensions
2WD Wheelbase208 cmReference
4WD Wheelbase205 cmReference
Weight6168 to 6796 poundsReference
Front tire7.5-20Reference
Rear tire13.6R38Reference
Standard tires (ag)Front: 7.5-20. Rear: 13.6R38Reference
4WD Standard tires (ag)Front: 13.6R38. Rear: 13.6R38Reference
2WD Length379 cmReference
4WD Length370 cmReference
2WD Width196 cmReference
4WD Width201 cmReference
Height (hood)171 cmReference
2WD Weight2797 kgReference
4WD Weight3082 kgReference
2WD Clearance (front axle)76 cmReference
4WD Clearance (front axle)60 cmReference
2WD Clearance (drawbar)68 cmReference
4WD Clearance (drawbar)68 cmReference
2WD Front tread161 to 205 cmReference
4WD Front tread166 to 216 cmReference
Rear tread150 to 226 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
