Tractor · 1994Unverified
Massey Ferguson 384V
Massey Ferguson 384V — 304 Specialty Series · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
4905 to 5908 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Original price was $34,000 in 1999Reference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount ROPS. Cab available.Reference
Variants
384SnarrowReference
384GElow profileReference
384Vultra-narrowReference
384HChigh clearanceReference
Engine
Perkins 3.9L 4-cyl dieselReference
Fuel tank53.0 LReference
Perkins A4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Air cleanerdryReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
12-speed shuttleReference
24-speed creeperReference
TypeshuttleReference
Gears12 forward and reverseReference
Clutch305mm dry discReference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
Rear valves2 to 5Reference
Pump flow42.4 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Engine RPM540@1960Reference
Dimensions
2WD Wheelbase207 cmReference
4WD Wheelbase201 cmReference
Weight4905 to 5908 poundsReference
Front tire7.5L-15Reference
2WD Rear tire14.9-24Reference
2WD Standard tires (ag)Front: 7.5L-15. Rear: 14.9-24Reference
4WD Standard tires (ag)Front: 7.5-18. Rear: 14.9-24Reference
Length369 cmReference
2WD Width140 cmReference
4WD Width122 cmReference
2WD Weight2224 kgReference
4WD Weight2679 kgReference
2WD Clearance (drawbar)39 cmReference
4WD Clearance (drawbar)34 cmReference
2WD Front tread99 to 121 cmReference
4WD Front tread108 to 138 cmReference
Rear tread87 to 152 cmReference
Steering wheel140 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Massey Ferguson 384V Height
Hood125 cmReference
Cab225 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
