Tractor · 1994Unverified

Massey Ferguson 394HC

Name: Massey Ferguson 394HC
Brand: Massey Ferguson

Massey Ferguson 394HC — 304 Specialty Series · 73 hp. Reference specifications; pending source verification.

The Massey Ferguson 394HC is a tractor of mid-range power output, rated at 73 hp. It was manufactured from 1994 to 1999. The tractor features a 4-cylinder diesel liquid-cooled engine paired with a 12-speed gearbox and four-wheel drive. Its operating weight ranges from 6510 to 7078 pounds, and it is suitable for operations spanning up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

73 hp

Weight

6510 to 7078 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

73 hp

Recorded weight

2952 kg

Transmissions

12-speed shuttle

Production years

1994-1999

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

High-Clearance tractorReference

Built in ItalyReference

Original price was $31,600 in 1999Reference

Two- or four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Four-post ROPS.Reference

Variants

394SnarrowReference

394GElow profileReference

394HChigh clearanceReference

Engine

Perkins 4.1L 4-cyl dieselReference

Fuel tank79.5 LReference

Perkins A4.248Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.1 LReference

Bore/Stroke101 x 127 mmReference

Air cleanerdryReference

Rated RPM2200Reference

Starter volts12Reference

Transmission

12-speed shuttleReference

24-speed creeperReference

TypeshuttleReference

Gears12 forward and reverseReference

Clutch305mm dry discReference

TypecreeperReference

Gears24 forward and 12 reverseReference

PTO & Hydraulics

PTO (claimed)54.4 kWReference

Rear valves2 to 3Reference

Pump flow54.1 lpmReference

Rear TypeIIReference

Rear lift (at ends)3851 kgReference

Rear PTOindependentReference

Rear PTO Type540/750Reference

Rear PTO Type540/1000Reference

Engine RPM540@1960Reference

Dimensions

2WD Wheelbase214 cmReference

4WD Wheelbase212 cmReference

Weight6510 to 7078 poundsReference

Front tire7.5-20Reference

2WD Rear tire13.6R38Reference

2WD Standard tires (ag)Front: 7.5-20. Rear: 13.6R38Reference

4WD Standard tires (ag)Front: 13.6R38. Rear: 13.6R38Reference

2WD Length379 cmReference

4WD Length381 cmReference

2WD Width196 cmReference

4WD Width201 cmReference

2WD Height (hood)171 cmReference

4WD Height (hood)166 cmReference

2WD Weight2952 kgReference

4WD Weight3210 kgReference

2WD Clearance (front axle)76 cmReference

4WD Clearance (front axle)60 cmReference

Clearance (drawbar)68 cmReference

2WD Front tread161 to 205 cmReference

4WD Front tread166 to 216 cmReference

Rear tread150 to 226 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
