The Massey Ferguson 397 is a tractor with a power rating of 80 hp, positioning it within the middle of its class in terms of power output. Manufactured from 1987 to 1994, the 397 features a 4-cylinder engine, coupled with a hydrostatic transmission and four-wheel drive system. It has a listed weight of 3640 kg and is suited for tasks covering approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
3640 kg
Catalogue coverage
Variants represented
2
Richest spec table
30 rows
Recorded power
80 hp
Recorded weight
3640 kg
Transmissions
24-speed
Production years
1987-1994
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
standardReference
Engine
Perkins 4.1L 4-cylReference
Fuel tank101.8 LReference
Engine59.7 kWReference
Perkins A4.248Reference
4-cylinderReference
Displacement4.1 LReference
Bore/Stroke101 x 127 mmReference
Power59.7 kWReference
Rated RPM2200Reference
Torque283.0 NmReference
Torque RPM1400Reference
Transmission
24-speedReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Total flow37.1 lpmReference
Rear lift3000 kgReference
Rear lift3650 kgReference
Rear PTO Type540/1000/groundReference
Dimensions
Wheelbase242 cmReference
Weight3640 kgReference
Front tire13.6-24Reference
Rear tire16.9-34Reference
Ag front13.6-24Reference
Ag rear16.9-34Reference
Length385 cmReference
Height266 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
