Tractor · 1987Unverified
Massey Ferguson 399
Massey Ferguson 399 — Model year 1987-19901991-1997 · 95 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
95 hp
Max power
74.3 kW
Weight
7400 to 8560 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in Coventry, EnglandReference
Original price was $37,800 in 1997Reference
Two- or four-wheel driveReference
Power steeringReference
Differential wet disc brakesReference
Two-post fixed ROPS. Cab optional with air-conditioning.Reference
Engine
Perkins 6.0L 6-cyl dieselReference
Engine76.5 kWReference
Drawbar (tested)67.5 kWReference
Perkins 1006.6Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.0 LReference
Bore/Stroke100 x 127 mmReference
Power76.5 kWReference
Fuel systemdirect injectionReference
Air cleanerdual dry elementReference
Compression16.5:1Reference
Rated RPM2200Reference
Idle RPM750-2310Reference
Torque429.9 NmReference
Torque RPM1200Reference
Firing order1-5-3-6-2-4Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity20.1 LReference
Oil capacity15.4 LReference
Oil change250 hReference
Max power74.3 kWReference
Power at rated engine speed70.9 kWReference
Max power67.5 kWReference
Transmission
12-speed synchromeshReference
12-speed synchronized shuttleReference
18-speed two-speed power shiftReference
TypesynchromeshReference
Gears12 forward and 4 reverseReference
Three gears in two ranges with two-speed high/low shift.Reference
TransmissionSide ShiftReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
TransmissionSpeedshiftReference
Typetwo-speed power shiftReference
Gears18 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)67.1 kWReference
PTO (tested)74.3 kWReference
Hydraulic system47.3 LReference
Typeopen centerReference
Capacity47.3 LReference
Pressure206.8 barReference
Valves2Reference
Pump flow27.3 lpmReference
Pump flow36.0 lpmReference
Total flow63.6 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1968 kgReference
Rear lift (at ends)2497 kgReference
Rear lift (at ends)3678 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1893Reference
Engine RPM1000@1900Reference
Power at rated PTO speed73.9 kWReference
Capacities
Fuel126.0 LReference
Dimensions
2WD Wheelbase257 cmReference
4WD Wheelbase263 cmReference
Weight7400 to 8560 poundsReference
Front tire10.00-16Reference
2WD Rear tire16.9/14-38Reference
2WD Standard tires (ag)Front: 10.00-16. Rear: 16.9/14-38Reference
4WD Standard tires (ag)Front: 13.6-28. Rear: 16.9/14-38Reference
2WD Length415 cmReference
4WD Length429 cmReference
Width197 cmReference
2WD Clearance (front axle)57 cmReference
4WD Clearance (front axle)42 cmReference
Clearance (drawbar)43 cmReference
2WD Front tread136 to 197 cmReference
Rear tread140 to 212 cmReference
Rear tread152 to 222 cmReference
2WD ROPS3356 kgReference
4WD ROPS3587 kgReference
2WD Cab3651 kgReference
4WD Cab3882 kgReference
Steering wheel190 cmReference
Massey Ferguson 399 attachments
front-end loaderReference
399 Serial Number Location
Serial number plate on the right side of the tractor, near the brake pedals.Reference
399 Serial Numbers
1986U01001Reference
1987V01001Reference
1988N01001Reference
1989P01001Reference
1990R01001Reference
1991S01001Reference
1992A01001Reference
1993B01001Reference
1994C01001Reference
1995D01001Reference
1996E01001Reference
1997F01001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Batteries2Reference
Battery CCA420Reference
Battery volts12Reference
Massey Ferguson 399 Height
ROPS264 cmReference
Cab268 cmReference
Exhaust262 cmReference
Test results
Diesel 12-speed 4WDNovember 1990 - December 1990, Link: OCED Tractor Test 1312 fileReference
PTO performanceReference
Fuel use22.7 l/hourReference
Fuel use22.0 l/hourReference
Drawbar performanceReference
Fuel use23.5 l/hourReference
Gear 1H used for power test.Reference
Max pull4415 kgReference
Gear 12.33 used for pull test.Reference
Speeds
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
