Tractor · 2001Unverified
Massey Ferguson 415N
Massey Ferguson 415N — 400 Series · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
4475 to 4872 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Built in Canoas, BrazilReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Wet disc brakesReference
Open operator station. Mid-mount two-post folding ROPS optional.Reference
Variants
415utilityReference
415NnarrowReference
Engine
Perkins 2.5L 3-cyl dieselReference
Engine34.3 kWReference
Perkins AD3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power34.3 kWReference
Fuel systemdirect injectionReference
Rated RPM2250Reference
Torque181.0 NmReference
Torque RPM1350Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed sliding spur gearReference
Typesliding spur gearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)29.6 kWReference
Hydraulic system42.0 LReference
Capacity42.0 LReference
Pressure210.0 barReference
Pump flow17.0 lpmReference
Rear TypeIIReference
Controldraft, position, and response controlReference
Rear PTOliveReference
Rear PTOindependent (optional)Reference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1900Reference
Capacities
Fuel57.2 LReference
Dimensions
Wheelbase200 cmReference
Weight4475 to 4872 poundsReference
Front tire6.00-16Reference
Rear tire14.9-24 (2WD)Reference
Standard tires (ag)Front: 6.00-16. Rear: 14.9-24 (2WD)Reference
Standard tires (ag)Front: 12.5/80-18. Rear: 14.9-24 (4WD)Reference
Length346 cmReference
Height (steering wheel)156 cmReference
2WD Shipping weight2029 kgReference
4WD Shipping weight2209 kgReference
Front tread106 to 127 cmReference
Front tread132 to 139 cmReference
Rear tread119 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
